ROTARY GEAR PUMP
ELECTRONIC FOAM PROPORTIONING SYSTEM
Foam Concentrate Strainers
FS-15 STRAINER (P/N 510-0150-00-0)
(¾ Inch NPT Threads. Use With Class A
and thin Class B Foam Concentrates)
FS-25 STRAINER (P/N 510-0180-00-0)
(1 Inch NPT Threads. Use With Class A
and Class B Foam Concentrates)
In-Line Strainer/Valve Assembly (P/N 510-0190-01-0)
(Do Not Use If Subject to Flushing Water Pressure)
Hale FS Series Strainers (Use When Strainer is Subjected to Flushing Water Pressure)
Manual Single Tank (MST) Selector
Provides FoamPump Flushing Capabilities for a Single Tank System
(P/N 538-1490-12-0)
Single Foam Concentrate Tank Options
Single Tank Instruction Placard/System
Diagram
(P/N 101-1631-12-0)
MST Wiring Harness
(P/N 513-0320-04-0)
MST Wiring Harness Extension
72 inches (1829 mm) long
(P/N 513-0320-07-0)
