EPSON Stylus Color 440/640/740 Revision B
Chapter 7 Appendix 199
Table A-38. Part List for Stylus Color 440/640 (3/4)
Part Name
578 Push Nut, 2 724 Roller, LD, Sub
579 Harness, HP 725 Holder, Roller, LD, Sub, Right
580 Harness, PE 726 Pad Assy., Left
581 Harness, ASF 727 Lever, Pad, Release, Left
586 CBS-Tite Screw 728 Holder, Edge Guide, Left
587 CBS-Tite Screw, M3x6 729 Lever, Paper Return, Left
588 CBS-Tite (P4) Screw, 3x6, F/Zn 730 Holder, Roller, LD, Sub, Left
589 Leaf Spring, 6.2x0.15x11 731 Roller Assy., LD, Left
590 Plain Washer, 2.6x0.5x8 732 Roller Assy., LD, Right
700 Printehead 733 Cover, Roller, LD, Left
701 Fastener, Head 734 Cover, Roller, LD, Right
702 Torsion Spring, 49 735 Compression Spring, 1.961
703 CBP-Tite Screw, 3x6, F/Zn 736 Lever, Fixing, Edge Guide;B
704 Cable, Head 737 Tension Spring, 0.088
705 Holder, Cable 738 Shaft, Roller, LD
706 Spacer, Cable Head 739 Lever, Hopper, Release
707 Frame, ASF;B 740 Wheel, Detection
708 Hopper 741 Lever, Brake
709 Edge Guide 742 Pad, Brake
710 Cork 743 Torsion Spring, 41.2
711 Slider, Edge Guide 744 Bushing, Fixing, Shaft
712 Compression Spring, 3.23 745 Sheet, Paper Feed
713 Pad, Brake, Edge Guide 746 Holder, Sheet, Paper Feed
714 Reinforcing Plate, Hopper 747 Shaft, Mouting, CR
716 Pad Assy., Right 748 CBS (P4) Screw, 3x6, F/Zn
717 Lever, Pad, Release, Right 750 Spur Gear, 34
718 Bar Spring, Holder, Pad 751 Paper Guide, Lower
719 Holder, Edge Guide, Right 752 Absorber, Waste Ink, Large
720 Compression Spring, 1.17 753 Tray, Absorber
721 Tension Spring, 0.62 754 Spacer, Tray
722 Lever, Paper Return, Right 755 Bushing, Fixing, Shaft, Left
723 Tension Spring, 0.294 756 Paper Support, Sub, Upper
Table A-39. Part List for Stylus Color 440/640 (4/4)
757 Holder, Paper Support, Sub, Upper
758 Torsion Spring, 0.29
759 Cover, Cartridge, Bk
760 Cover, Cartridge, C;B
761 Separator, Cartridge, Bk
762 Separator, Cartridge, C
763 Detector, HP
764 Cork;B
765 Cleaner, Head, ASP
