A.1 Connector Summary

This section gives information on connectors and their pin assignment.
Since all connectors and their pin assignments except for CN8
(printhead) are common for Stylus Color 440 and Stylus Color 640, they
are included in one section (

Section A.1.1

.) Refer to

Section A.1.2

for

the connector summary for Stylus Color 740. Each section includes the
following information.

Section A.1.1 (Stylus Color 440/640)

C206MAIN-B, C255MAIN (Stylus Color 440)

C256MAIN (Stylus Color 640)

C206PSB/PSE (Stylus Color 440, Stylus Color 640)

Printer Mechanism

Section A.1.2 (Stylus Color 740)

C257MAIN

C257PSB/PSE

Printer mechanism
