EPSON Stylus Color 440/640/740
Revision A
Chapter 7
Appendix
170
Table A-20.
Stylus Color 440/640
EEPROM Address Map
Address
Explanation
Setting
QPIT
Settings
Factory
Settings
00H
Password 0
54H
-
01H
0FH
-
02H
Market
0: Word
1: Japan
2: Custom (MJ-)
∗∗
3: Custom (Stylus Color)
∗∗
4: Custom (other name)
∗∗
00H
(
∗
1)
(*3)
03H
1st dot adjustment -40
≤
n
≤
40
(by 1/1440 inch)
00H
(
∗
1)
04H
Bi-D adjustment
data
-36
≤
n
≤
36
(by 1/1440 inch)
00H
(
∗
1)
05H
Uni-D adjustment
data
-36
≤
n
≤
36
(by 1/1440 inch)
00H
(
∗
1)
06H
Stylus Color 440
Reserved
00H
-
Stylus Color 640
CG
0: STD
1: NLSP
00H
(
∗
1)
07H
Reserved
00H
-
08H
Carriage speed
adjustment data
-4
≤
n
≤
4
(by G.A timer unit)
00H
(
∗
1)
09H
Stylus Color 440
Reserved
00H
-
Stylus Color 640
Carriage speed
adjustment data
for 1440 dpi
-4
≤
n
≤
4
(by G.A timer unit)
00H
(
∗
1)
0AH
Head actuator
rank ID for VhN
12H
(
∗
1)
0BH
Head actuator
rank ID for Twh2
01H
(
∗
1)
Table A-21.
Stylus Color 440/640
EEPROM Address Map (Continued)
Address
Explanation
Setting
QPIT
Settings
Factory
Settings
0CH
Stylus Color 440
Reserved
00H
(
∗
1)
Stylus Color 640
Head actuator
rank ID for VhM
10H
(
∗
1)
0DH
Stylus Color 440
Reserved
00H
-
Stylus Color 640
Head actuator
rank ID for VhMS
00H
(
∗
1)
0EH
Reserved
00H
-
0FH
Reserved
00H
-
10H
Password 1
5AH
-
11H
0FH
-
12H
Custom EEPROM
sub number
00H
00H
13H
00H
00H
14H
00H
00H
15H
00H
00H
16H
Reserved
00H
-
17H
Reserved
00H
-
18H
CPSI password
00H
00H
19H
00H
00H
1AH
00H
00H
1BH
00H
00H
1CH
CPSI flags
bit7: CPSI license
0: Disable, 1: Enable
bit6: CPSI Font license
0: Disable, 1: Enable
00H
00H
1DH
Reserved
00H
-
1EH
Reserved
00H
-
1FH
EEPROM
Revision
42H
-
