EPSON Stylus Color 440/640/740 Revision A
Chapter 7 Appendix 174
A.2.2 EEPROM Address Map (Stylus Color 740)
This section provides EEPROM address map for the Stylus Color 740.
l
C A U T I O N EEPROM map in this section only applies to Stylus
Color 740.
If you need EEPROM map for Stylus Color 440/640,
return to Section A.2.1. (They are combined in one
table.)
Table A-29. Stylus Color 740 EEPROM Address Map
Address Explanation Setting
QPIT
Settings
Factory
Settings
00H Password 0 0FH -
01H 5AH -
02H EEPROM
mapping revision 41H -
03H Board lD 0: On-board RAM is 8 Mbit
1: On-board RAM is 16 Mbit 00H (*1)
04H CG 0: STD, 1: NLSP 00H (*1)
05H Market lD 0: Standard (World)
2: Custom 00H (*1)
06H Custom EEPROM
sub number 00H 00H
07H 00H 00H
08H 00H 00H
09H 00H 00H
0AH Head actuator
rank lD for VhN 00H (*1)
0BH Head actuator
rank ID for Vh
µ
00H (*1)
0CH Head actuator
rank ID for VhL 00H (*1)
0DH Head actuator
rank lD for AR 00H (*1)
0EH Head rank MW-ID 00H (*1)
0FH Reserved for
Head-lD 00H -
10H Reserved for
Head-lD 00H -
11H Reserved for
Head-ID 00H -
12H Head actuator
rank lD for lwAB 00H (*1)
13H Head actuator
rank lD for lwCD 00H (*1)
