EPSON Stylus Color 440/640/740 Revision A
Chapter 4 Disassembly and Assembly 102
4.1.3 Specification for Screws
Table 4-2 shows screw specifications. During assembly and
disassembly, make sure that the specified types of screws are used at
proper locations, referring to the table below. Note that the screw
numbers described in the manual correspond to the numbers in the
table.
Table 4-2. Screw Characteristic
No. Body Name Size
1 +Bind, S-tight M3X6
2 +Bind, S-tight M3X10
3 +Bind, P-tight
(CBP tight) M3X6
4 +Bind, P-tight
(CBP tight) M3X10
5 +Bind, P-tight
(CBP tight) M3X8
6 +Pan head
(CP)
M3X4
7 +Bind, S-tight,
Sems
R2(CBS Sems) M3X6
