Page 128
EPSON Stylus Color 440/640/740
Revision A
Chapter 4
Disassembly and Assembly
128
4.2.4.10 Removing the HP Detector
1. Remove the housing. (Refer to Section 4.2.1.)
2. Remove the cable from the HP detector and take it out after
releasing the fixed hook.
Figure 4-24. Removing the HP Detector
H P D e t e c t o r
