EPSON Stylus Color 440/640/740 Revision A
Chapter 5 Adjustment 138
5.2.2.2.1 Registering the printer model name
1. If no model name is registered, the screen shown below appears. Press
the E key while pressing the Alt key, and the program advances to
the Model Name Input Screen.
Figure 5-9. Model Name Null Condition
Figure 5-10. Model Name Input Screen
2. Type the correct model name, referring to the box below.
3.
After a few seconds, the model name appears on the Initial Screen
(2) (Figure 5-7). Proceed to one of the following steps.
M S - D O S P r o m p t - S C 6 4 0
A u t o
S t a r t i n g S E R V I C E P R O G R A M
P r i n t e r m o d e l n a m e i s n o t r e g i s t e r e d .
N o t e :
T h i s s c r e e n i s c o m m o n f o r S t y l u s C o l o r 4 4 0 , 6 4 0 ,
a n d 7 4 0 e x c e p t f o r t h e p r o g r a m n a m e .
M S - D O S P r o m p t - S C 6 4 0
A u t o
P l e a s e t y p e t h e p r i n t e r m o d e l n a m e ,
a n d t h e n p r e s s t h e E n t e r k e y .
> > _
N o t e :
T h i s s c r e e n i s c o m m o n f o r S t y l u s C o l o r 4 4 0 , 6 4 0 ,
a n d 7 4 0 e x c e p t f o r t h e p r o g r a m n a m e .
Stylus _ COLOR _ 440
Stylus _ COLOR _ 640
Stylus _ COLOR _ 740
C A U T I O N
" - "means a space.
Be sure to type the model name in exactly the
same way as shown above, paying attention
to the text formats, uppercase or lowercase.
If you mistype the model name, the program
will automatically return to the model name
input screen (Figure 5-10).
C A U T I O N For Stylus Color 740:
If the printer is Stylus Color 740, you must set
the correct CG,
NLSP or Standard. Therefore, be
sure to read the instructions below carefully to
take the proper steps.
If the printer is Stylus Color 440/640, return to Section
5.2.2.2 / Step 6 .
If the printer is Stylus Color 740, proceed to Section
5.2.2.2.2 / Step 1 .
