EPSON Stylus Color 440/640/740
Revision A
Chapter 7
Appendix
177
Table A-34.
Stylus Color 740
EEPROM Address Map (Coutinued)
Address
Explanation
Setting
QPIT
Settings
Factory
Settings
4CH
Ink counter Cm
00H
00H
4DH
00H
00H
4EH
00H
00H
4FH
00H
00H
50H
Ink counter Cc
00H
00H
51H
00H
00H
52H
00H
00H
53H
00H
00H
54H
Ink counter Clm
00H
00H
55H
00H
00H
56H
00H
00H
57H
00H
00H
58H
Ink counter Clc
00H
00H
59H
00H
00H
5AH
00H
00H
5BH
00H
00H
5CH
Ink counter Rb
00H
00H
5DH
00H
00H
5EH
Ink counter Ry
00H
00H
5FH
00H
00H
60H
Ink counter A
00H
00H(*2)
61H
00H
00H(*2)
62H
Power off time
00H
00H(*2)
63H
00H
00H(*2)
64H
CL time
00H
00H(*2)
65H
00H
00H(*2)
66H
accumulated
printing time
00H
00H
67H
00H
00H
68H
Reserved for ink
system
00H
-
69H
Reserved for ink
system
00H
-
Table A-35.
Stylus Color 740
EEPROM Address Map (Coutinued)
Address
Explanation
Setting
QPIT
Settings
Factory
Settings
6AH
Printer-ID Strings
[22]
00H
00H
6BH
00H
00H
6CH
00H
00H
6DH
00H
00H
6EH
00H
00H
6FH
00H
00H
70H
00H
00H
71H
00H
00H
72H
00H
00H
73H
00H
00H
74H
00H
00H
75H
00H
00H
76H
00H
00H
77H
00H
00H
78H
00H
00H
79H
00H
00H
7AH
00H
00H
7BH
00H
00H
7CH
00H
00H
7DH
00H
00H
7EH
00H
00H
7FH
00H
00H
*1:
Adjusted at factory
*2:
Initialized after panel initialization of EEPROM is performed.
*3: BUSY signal delay time form fall-edge of a -STB signal.
(Fast: Maximum 1MB/s, Slow: Maximum 600KB/s
*4: Select IEEE1284 transfer mode. (ECP or Nibble)
*5: Enable or disable reverse transfer. (When disabled, ignore -SLIN signal
