EPSON Stylus Color 440/640/740 Revision A
Chapter 4 Disassembly and Assembly 126
Figure 4-21. Removing the Paper Eject Roller Assembly
Figure 4-22. Removing the PF Roller Assembly
F r o n t P a p e r G u i d e ; B
E j e c t P a p e r R o l l e r
A s s e m b l y
P F R o l l e r A s s e m b l y
A l i g n t h e p r o t r u s i o n i n t h e P F r o l l e r
a s s e m b l y w i t h t h e h o l e i n t h e f r a m e f o r
h o l d i n g t h e s h a f t .
