EPSON Stylus Color 440/640/740 Revision B
Chapter 7 Appendix 198
A.5 Part List
A.5.1 Part List for Stylus Color 440/640
Table A-36. Part List for Stylus Color 440/640 (1/4)
Part Name Part Name
100 Housing;B 128 Mini Clamp
101 Cover, Printer;B 180 Label, Caution 1;B
102 Paper Support;B 181 Label, Accessory B
103 Stacker Assembly;B 182 Label, Accessry C
104 Panel Assembly, Right;B 183 Label, Lever Cartridge, Black
105 Shield Plate, Panel 184 Label, Lever Cartridge, Color
106 Housing, Panel, Left;B 200 Board Assembly, Main
107 Button, P/S;B 300 Board Assembly, Power Supply
108 Groundign Plate 330 Harness
109 Cover, Shield Plate, M/B, Right 400 Power Cable Assembly
110 Cover, Shield Plate, M/B, Left 450 Board Assembly, Panel
111 Cover, Cable 500 Printer Mechanism
112 Cover, Inlet, Upper;B 501 Frame Assembly, Left
113 Cover, Inlet, Lower;B 502 Motor Assembly, PF
114 Shiled Plate, M/B;C 503 Spur Gear, 23.2
115 Logo Plate 504 Combination Gear, 16, 40.8
116 Housing, Sub, Right;B 505 Frame, Right
117 Housing Sub, Left;B 506 Frame, Top
119 Foot 507 Motor Assembly, CR
121 CP Screw, M3x6 508 Pump Assembly
122 CBS-Tite Screw, M3x6 509 Cap Assembly
123 CB(O) Screw, 4x5, F/Zg 510 Frame, Bottom
124 CBS-Tite Screw, M3x10 511 Sheet, Protection, Head
125 CBP-Tite Screw, M3x8, F/Zn 512 Frame, Front
126 CBP-Tite Screw, M3x10, F/Zn 513 Bushing, Parallelism Adjustment,
Left
Table A-37. Part List for Stylus Color 440/640 (2/4)
Part Name Part Name
514 Bushing, Parallelism Adjustment,
Right
546 Paper Guide, Right
515 Paper Guide, Rear 547 Paper Guide, Left
516 Roller, PF 548 Shaft, Paper Guide, Upper
517 Compression Spring, 5.85 549 Shaft, Roller, Driven
518 Bushing, 12, Left 550 Roller, Driven;D
519 Lever, Change 551 Torsion Spring, 117.6
520 Spur Gear, 26.4 552 Board Assembly, PE
521 Spacer, C-ring 553 Holder, PE
522 Scallop Sp-AW, 2x16, F/B 554 Lever, PE
523 Compression Spring, 0.9 555 Torsion Spring, 0.22
524 Spur Gear, 67.2 556 Sheet, Guide Plate, Cable
525 Spacer, Fixing, Roller, PF 557 Guide Plate, Cable
526 Spacer, Fixing, Roller, PF;B 558 Sheet, Cable
527 Crescent Ring 559 Detector, PE
528 Plain Washer12.2x0.5x15 560 Carriage Assembly
529 Roller Assembly, Paper Eject 561 Lever, Adjust
530 Bushing, 6 562 Grouding Plate, Head
531 Retaining Ring, Type-E(4) 563 Oil Pad
532 Spur Gear, 36 564 Slider, CR
533 Spur Gear, 11 565 Timing Belt
534 Plain Washer, 4.1x0.5x6.5 566 Shaft, CR, Guide
535 Paper Guide, Front 567 Pulley Assembly, Driven
536 Grounding Spring, Paper Eject 568 Holder, Pulley, Driven
538 Frame, Paper Eject 569 Compression Spring, 19.6
539 Holder, Star Wheel, Right 570 Lever, PG
540 Holder, Star Wheel, Left 571 Lever, PG, Sub
541 Holder, Star Wheel, Front 572 Torsion Spring, 63.7
542 Star Wheel Assembly, 8(Natural) 573 Combination Spring, 6, 34.4
543 Star Wheel 8;B 574 Combination Spring, 8, 30
544 Bar Spring, Star Wheel 576 Absorber, Slider, Cap
545 Paper Guide, Upper 577 Bushing, Fixing, Combination Gear
