Configuration and Use Manual 85
Pressure Compensation and Temperature Compensation
Me
asu
reme
nt P
er
form
anc
e
Defaults
T
rou
b
lesho
o
ti
ng
Compensation
Figure 9-2 Configuring pressure compensation with a DeviceNet tool
9.3 External temperature compensation
External temperature compensation can be used with the petroleum measurement application or the
enhanced density application.
Note: The external temperature value is used only for calculation of the derived variable in enhanced
density applications or the CTL value in petroleum measurement applications. The temperature value
from the sensor is used for all other calculations that require a temperature value.
Set flow calibration
pressure
Set flow factor
Class: Calibration Object (0x65)
Instance: 1
Attribute ID: 32
Data type: REAL
Service: Set
Set density factor
Class: Calibration Object (0x65)
Instance: 1
Attribute ID: 31
Data type: REAL
Service: Set
Class: Calibration Object (0x65)
Instance: 1
Attribute ID: 30
Data type: REAL
Service: Set
Enable pressure
compensation
Class: Calibration Object (0x65)
Instance: 1
Attribute ID: 27
Data type: BOOL
Value:
· 0 = disabled
· 1 = enabled
Set pressure unit
Class: Calibration Object (0x65)
Instance: 1
Attribute ID: 29
Value: See Table 6-7
Service: Set
Yes
Use static
pressure value?
No
Set up output
assembly (2)
Class: Calibration Object (0x65)
Instance: 1
Attribute ID: 28
Data type: REAL
Service: Set
Set static value
(1) Pressure measurement unit must
be configured to match pressure unit
used by external device. See
Section 6.3.
(2) See Section 9.4.
