154
Micro Motion
®
Model 2400S Transmitters for DeviceNet
™
Device Profile
32
9-wire cable
RTD resistance
REAL
Get
V
The resistance of the
9-wire cable
Unit = ohms
33
Meter RTD
resistance
REAL
Get
V
The resistance of the
meter RTD
Unit = ohms
34
Number of
power cycles
UINT
Get
V
The number of transmitter
power cycles
35
Power on time
Unsigned 32
Get
Reset
(1)
V
The cumlative amount of
time the tranmitter has
been on since the last
reset (Class 0x01,
Attribute 0x05)
Seconds since last
reset
36
Line RTD
REAL
Get
V
The resistance of the
process line RTD
Unit = ohms
37
Actual target
amplitude
REAL
Get
V
The amplitude the
transmitter is attempting
to drive the sensor
Unit = mV/HZ
38
Input voltage
REAL
Get
V
The number of volts on
the power input terminals
Unit = volts
39
Drive current
REAL
Get
V
The drive current
Unit = milliamps
40
Alarm 7
UINT
Get
V
A collection of status bits
• 0x0001 = K1/FCF
Combination
Unrecognized
• 0x0002 = Warming
Up
• 0x0004 = Low Power
• 0x0008 = Tube not
Full
• 0x0010 = Meter Ver
Fault
• 0x0020 = Meter Ver
Info
• 0x0040 =UI PROM
error
• 0x0080 = Not Used
• 0x0100 = Not Used
0x0200 = Not Used
• 0x0400 = Not Used
• 0x0800 = Not Used
• 0x1000 = Not Used
• 0x2000 = Not Used
• 0x4000 = Not Used
• 0x8000 = Not Used
Table C-7
Diagnostics Object (0x66) – Instance 1 continued
Attrib
ID
Name
Data type
Service
Mem
Description
Comments
