Configuration and Use Manual 31
Required Transmitter Configuration
Requ
ired Co
nfi
g
u
ratio
n
Op
ti
on
al
Co
nfi
g
u
rati
o
n
Using the T
rans
m
itte
r
Us
ing a De
vice
Net T
o
ol
CUFT/D ft3/day ft 3 /day 0x0816 Cubic feet per day
M3/S m3/sec m 3 /s 0x1405 Cubic meters per second
M3/MIN m3/min m 3 /min 0x080F Cubic meters per minute
M3/H m3/hr m 3 /hr 0x0810 Cubic meters per hour
M3/D m3/day m 3 /day 0x0811 Cubic meters per day
USGPS US gal/sec gal/s 0x1408 U.S. gallons per second
USGPM US gal/min gal/min 0x1409 U.S. gallons per minute
USGPH US gal/hr gal/hr 0x140A U.S. gallons per hour
USGPD US gal/d gal/day 0x0817 U.S. gallons per day
MILG/D mil US gal/day MillionGal/dday 0x0820 Million U.S. gallons per day
L/S l/sec l/s 0x1406 Liters per second
L/MIN l/min l/min 0x0812 Liters per minute
L/H l/hr l/hr 0x0813 Liters per hour
MILL/D mil l/day MillionL/day 0x0821 Million liters per day
UKGPS Imp gal/sec ImpGal/s 0x0818 Imperial gallons per second
UKGPM Imp gal/min ImpGal/min 0x0819 Imperial gallons per minute
UKGPH Imp gal/hr ImpGal/hr 0x081A Imperial gallons per hour
UKGPD Imp gal/day ImpGal/day 0x081B Imperial gallons per day
BBL/S barrels/sec bbl/s 0x081C Barrels per second (1)
BBL/MN barrels/min bbl/min 0x081D Barrels per minute (1)
BBL/H barrels/hr bbl/hr 0x081E Barrels per hour (1)
BBL/D barrels/day bbl/day 0x081F Barrels per day (1)
BBBL/S Beer barrels/sec Beer bbl/s 0x0853 Beer barrels per second (2)
BBBL/MN Beer
barrels/min Beer bbl/min 0x0854 Beer barrels per minute (2)
BBBL/H Beer barrels/hr Beer bbl/hr 0x0855 Beer barrels per hour (2)
BBBL/D Beer
barrels/day Beer bbl/day 0x0856 Beer barrels per day (2)
(1) Unit based on oil barrels (42 U.S. gallons).
(2) Unit based on beer barrels (31 U.S. gallons).
Table 6-4 Volume flow measurement units – Gas
Volume flow unit
Display ProLink II DeviceNet tool DeviceNet code Unit description
NM3/S Nm3/sec Nml m 3 /s 0x0835 Normal cubic meters per second
NM3/MN Nm3/min Nml m 3 /min 0x0836 Normal cubic meters per minute
NM3/H Nm3/hr Nml m 3 /hr 0x0837 Normal cubic meters per hour
NM3/D Nm3/day Nml m 3 /day 0x0838 Normal cubic meters per day
NLPS NLPS Nml l/s 0x083D Normal liter per second
Table 6-3 Volume flow measurement units – Liquid continued
Volume flow unit
Display ProLink II DeviceNet tool DeviceNet code Unit description
