To reset an individual totalizer or inventory:

1. Click

ProLink > Totalizer Control

ProLink > ED Totalizer Control

(if the enhanced

density application is enabled).

2. Click the appropriate button (e.g.,

Reset Mass Total

Reset Volume Inventory

Reset Net

Mass Total

With a DeviceNet tool

Using a DeviceNet tool, three methods are available for totalizer and inventory control:

•

EDS – If you have imported the EDS into your DeviceNet tool, you can perform the following
functions from the EDS user interface:

Reset mass totalizer

Reset mass inventory

Reset liquid volume totalizer

Reset liquid volume inventory

Reset API reference volume total

Reset API reference volume inventory

Reset gas standard volume totalizer

Reset gas standard volume inventory

Reset ED standard volume total

Reset ED net mass total

Reset ED net volume total

Reset ED standard volume inventory

Reset ED net mass inventory

Reset ED net volume inventory

•

Explicit write – Using a Set, a Reset Total, or a Reset Inventory service, you can perform the
functions listed in Table 7-8.

•

Output assemblies – Five output assemblies are provided, supporting the functions listed in
Table 7-9. See the manual entitled Micro Motion Model 2400S Transmitters for DeviceNet:
Device Profile for detailed information.

Table 7-8

Totalizer and inventory control with a DeviceNet tool using explicit write

To accomplish this

Use this device profile data

Stop all totalizers and inventories

Analog Input Point Object (0x0A)
Instance: 0
Attribute ID: 100
Service: Set
Value: 0

Start all totalizers and inventories

Analog Input Point Object (0x0A)
Instance: 0
Attribute ID: 100
Service: Set
Value: 1

Reset all totalizers

Analog Input Point Object (0x0A)
Instance: 0
Attribute ID: 101
Service: Set
Value: 1
