Configuration and Use Manual 135
D
e
vice Pr
ofile
In
de
x
Displa
y Codes
Men
u
s
Appendix B
Menu Flowcharts
B.1 Overview
This appendix provides the following menu flowcharts for the Model 2400S DN transmitter:
• ProLink II menus
- Main menu – see Figure B-1
- Configuration menu – see Figures B-2 and B-3
• Display menus
- Off-line menu: Top level – see Figure B-4
- Off-line maintenance: Version information – see Figure B-5
- Off-line maintenance: Configuration – see Figure B-6
- Off-line maintenance: Zero – see Figure B-7
- Off-line maintenance: Meter verification – see Figure B-8
For information on the codes and abbreviations used on the display, see Appendix D.
B.2 Version information
These menu flowcharts are based on:
• Transmitter software v1.0
• ProLink II v2.5
Menus may vary slightly for different versions of these components.
