Configuration and Use Manual 33
Required Transmitter Configuration
Requ
ired Co
nfi
g
u
ratio
n
Op
ti
on
al
Co
nfi
g
u
rati
o
n
Using the T
rans
m
itte
r
Us
ing a De
vice
Net T
o
ol
6.3.4 Temperature units
The default temperature measurement unit is ° C . See Table 6-6 for a complete list of temperature
measurement units.
6.3.5 Pressure units
The flowmeter does not measure pressure. You need to configure the pressure units if either of the
following is true:
• You will configure pressure compensation (see Section 9.2). In this case, configure the
pressure unit to match the pressure unit used by the external pressure device.
• You will use the Gas Wizard, you will enter a reference pressure value, and you need to change
the pressure unit to match the reference pressure value (see Section 8.2).
If you do not know whether or not you will use pressure compensation or the Gas Wizard, you do not
need to configure a pressure unit at this time. You can always configure the pressure unit later.
The default pressure measurement unit is PSI . See Table 6-7 for a complete list of pressure
measurement units.
Table 6-6 Temperature measurement units
Temperature unit
Unit description Display ProLink II DeviceNet tool DeviceNet code
° C ° C degC 0x1200 Degrees Celsius
° F ° F degF 0x1201 Degrees Fahrenheit
° R ° R degR 0x1202 Degrees Rankine
° K ° K Kelvin 0x1203 Kelvin
Table 6-7 Pressure measurement units
Pressure unit
Unit description Display ProLink II DeviceNet tool DeviceNet code
FTH2O Ft Water @ 68 ° F FtH2O(68F) 0x082D Feet water @ 68 °F
INW4C In Water @ 4 ° C InH2O(4C) 0x0858 Inches water @ 4 °C
INW60 In Water @ 60 ° F InH2O(60F) 0x0859 Inches water @ 60 °F
INH2O In Water @ 68 ° F InH2O(68F) 0x082C Inches water @ 68 °F
mmW4C mm Water @ 4 ° C mmH2O(4C) 0x085A Millimeters water @ 4 °C
mmH2O mm Water @ 68 ° F mmH2O(68F) 0x082E Millimeters water @ 68 °F
mmHG mm Mercury @ 0 ° C mmHg(0C) 0x1303 Millimeters mercury @ 0 °C
INHG In Mercury @ 0 ° C InHg(0C) 0x1304 Inches mercury @ 0 °C
PSI PSI psi 0x1300 Pounds per square inch
BAR bar bar 0x1307 Bar
mBAR millibar mbar 0x1308 Millibar
G/SCM g/cm2 g/cm 2 0x082F Grams per square centimeter
KG/SCM kg/cm2 kg/cm 2 0x0830 Kilograms per square centimeter
PA pascals PA 0x1309 Pascals
KPA Kilopascals kPA 0x130A Kilopascals
