2 Micro Motion ® Model 2400S Transmitters for DeviceNet ™
Before You Begin
1.4 DeviceNet functionality
The Model 2400S DN transmitter implements the following DeviceNet functionality:
• Baud rates:
- 125 kBaud
- 250 kBaud
- 500 kBaud
• I/O slave messaging:
- Polling
- Cyclic
• Configuration methods:
- Hardware switches
- EDS
- Custom software
1.5 Determining version information
Table 1-1 lists the version information that you may need and describes how to obtain the information.
1.6 Communication tools
Most of the procedures described in this manual require the use of a communication tool. The
following communication tools can be used:
• Transmitter display, if the transmitter was ordered with a display. The display provides only
partial configuration functionality.
• ProLink ® II software, v2.5 and later. ProLink II provides complete configuration functionality
for the transmitter, but does not provide DeviceNet configuration functionality.
• Pocket ProLink software, v1.3 and later. Pocket ProLink provides complete configuration
functionality for the transmitter, but does not provide DeviceNet configuration functionality.
• Customer-supplied DeviceNet tool. Capabilities depend on the tool.
Table 1-1 Obtaining version information
Component With ProLink II With DeviceNet tool (1)
(1) See Chapter 5 for more information.
With display
Transmitter software
revision
(2)
(2) Also represents the core processor version.
ProLink II title bar or
View/Installed Options/
Software Revision Identity Object (0x01)
Instance 1
Attribute 198 OFF-LINE MAINT/VER
Software revision
corresponding to revision
specified on ODVA
certificate Not available Identity Object (0x01)
Instance 1
Attribute 4 Not available
Hardware revision Not available Identity Object (0x01)
Instance 1
Attribute 105 Not available
