Configuration and Use Manual 23
Using a DeviceNet Tool
Requ
ired Co
nfi
g
u
ratio
n
O
ptio
nal
Con
fig
uration
Using the T
rans
m
itte
r
Us
ing a De
vice
Net T
o
ol
5.5 Default assemblies
The default assemblies used by the Model 2400S DN transmitter are listed and described in Table 5-1.
To change the default assemblies, see the flowchart in Figure 5-1.
Figure 5-1 Changing the default DeviceNet assemblies
Table 5-1 Default DeviceNet assemblies
Connection type Assembly type Instance ID Description Size (bytes) Data type
Polled Input 6 Status
Mass flow
Mass total
Mass inventory
Temperature
Density 21 BOOL
REAL
REAL
REAL
REAL
REAL
Output 54 Reset all totalizer
values 1 BOOL
Cyclic Input 6 Status
Mass flow
Mass total
Mass inventory
Temperature
Density 21 BOOL
REAL
REAL
REAL
REAL
REAL
Polled connection:
Input assembly
Polled connection:
Output assembly
Class: Connection Object (0x95)
Instance: 1
Attribute ID: 100
Data type: UINT
Value: See Table 7-2
Service: Set
Cyclic connection:
Input assembly
Class: Connection Object (0x95)
Instance: 1
Attribute ID: 101
Data type: UINT
Value: See Tables 7-8 and 9-1
Service: Set
Class: Connection Object (0x95)
Instance: 1
Attribute ID: 102
Data type: UINT
Value: See Table 7-2
Service: Set
