Configuration and Use Manual 159
Device Profile
D
e
vice Pr
ofile
In
de
x
Displa
y Codes
Men
u
s
C.6 Sensor Information Object (0x67)
83 Factory flow
signal offset at
zero flow REAL Get NV The flow signal offset at
zero flow when calibrated
at the factory Unit = microseconds
84 Discrete event
action code USINT Set V The action that will be
performed by the event
specified in Attribute 85 • 1 = Start sensor zero
• 2 = Reset mass total
• 3 = Reset volume
total
• 4 = Reset API volume
total
• 5 = Reset ED volume
total
• 6 = Reset ED net
mass total
• 7 = Reset ED net
volume total
• 8 = Reset all totals
• 9 = Start/stop all
totals
• 18 = Increment ED
curve
• 21 = Reset GSV total
85 Discrete event
assignment USINT Set NV The discrete event that is
assigned to the action
referenced in Attribute 84 • 57 = Discrete event 1
• 58 = Discrete event 2
• 59 = Discrete event 3
• 60 = Discrete event 4
• 61 = Discrete event 5
• 251 = None
(1) Service code 0x4D.
Table C-8 Sensor Information Object (0x67) – Instance 1
Attrib
ID
Name Data type Service Mem Description Comments
1 Sensor serial
number UDINT Set NV The serial number of the
sensor
2 Sensor type SHORT
STRING Get NV A string that represents
the type of sensor For example, F200,
CMF025
3 Sensor type
code USINT Set NV The type of sensor • 0 = Curved tube
• 1 = Straight tube
Table C-7 Diagnostics Object (0x66) – Instance 1 continued
Attrib
ID
Name Data type Service Mem Description Comments
