Configuration and Use Manual 163
Device Profile
D
e
vice Pr
ofile
In
de
x
Displa
y Codes
Men
u
s
C.9 Enhanced Density Object (0x6A)
7 CTL REAL Get V Current value
8 API reference
temperature REAL Set NV The reference
temperature to use in the
API calculations
9 API thermal
expansion
coefficient REAL Set NV The thermal expansion
coefficient to use in the
API calculations
10 API 2540 CTL
table type USINT Set NV The table type to use in
the API calculations • 17 = Table 5A
• 18 = Table 5B
• 19 = Table 5D
• 36 = Table 6C
• 49 = Table 23A
• 50 = Table 23B
• 51 = Table 23D
• 68 = Table 24C
• 81 = Table 53A
• 82 = Table 53B
• 83 = Table 53D
• 100 = Table 54C
11 Reset API
reference
volume total USINT Set V Resets the API reference
volume total • 1 = Reset
12 Reset API
reference
volume
inventory USINT Set V Resets the API reference
volume inventory • 1 = Reset
(1) Service code 0x4B.
(2) Service code 0x4C.
Table C-11 Enhanced Density Object (0x6A) – Instance 1
Attrib
ID
Name Data type Service Mem Description Comments
1 Density at
reference REAL Get V Current value
2 Density (fixed
SG units) REAL Get V Current value
3 Standard
volume flow rate REAL Get V Current value
4 Standard
volume total REAL Get
Reset
(1)
V Current value
5 Standard
volume
inventory REAL Get
Reset
(2)
V Current value
6 Net mass flow
rate REAL Get V Current value
7 Net mass flow
total REAL Get
Reset
(3)
V Current value
Table C-10 API Object (0x69) – Instance 1 continued
Attrib
ID
Name Data type Service Mem Description Comments
