160 Micro Motion ® Model 2400S Transmitters for DeviceNet ™
Device Profile
C.7 Local Display Object (0x68)
4 Sensor material USINT Set NV The material of the
sensor’s case • 0 = None
• 3 = Hastelloy C-22
• 4 = Monel
• 5 = Tantalum
• 6 = Titanium
• 19 = 316L stainless
steel
• 23 = Inconel
• 252 = Unknown
• 253 = Special
5 Liner material USINT Set NV The material of the
sensor’s liner • 0 = None
• 10 = PTFE (Teflon)
• 11 = Halar
• 16 = Tefzel
• 251 = None
• 252 = Unknown
• 253 = Special
6 Flange type USINT Set NV The type of process
connection on the sensor • 0 = ANSI 150
• 1 = ANSI 300
• 2 = ANSI 600
• 5 = PN 40
• 7 = JIS 10K
• 8 = JIS 20K
• 9 = ANSI 900
• 10 = Sanitary clamp
fitting
• 11 = Union
• 12 = PN 100
• 252 = Unknown
• 253 = Special
Table C-9 Local Display Object (0x68) – Instance 1
Attrib
ID
Name Data type Service Mem Description Comments
1 Scroll rate USINT Set NV The rate at which each
variable will be displayed Unit = seconds
2 Backlight control BOOL Set NV Whether the backlight is
on or off • 0 = Off
• 1 = On
3 Backlight
intensity USINT Set NV The brightness of the
backlight 0 (off) to 63 (full on)
4 Display variable
1 USINT Set V Displays the variable
associated with the code
on the local display See Table C-15 for
codes. All codes are
valid except for 251
(None).
Table C-8 Sensor Information Object (0x67) – Instance 1 continued
Attrib
ID
Name Data type Service Mem Description Comments
