Using MRC
The MRC Interface
The MRC Interface
The MRC window is divided into two main sections. In the left-hand section is the navigation
pane containing links to pages within MRC. To open a page, click a link in the navigation pane.
The corresponding page displays in the right-hand section.
An orange dot appears on the navigation pane to the left of the link indicating that the page is
open.
Using Tabbed Tables
All pages of the ‘Configuration’ and ‘Router Tools’ sections have a ‘Network Frame Summary’ at
the bottom of the page. The summary section is divided into tabs. To bring a tab to the front,
click the tab title.
Only tables that apply to the tasks to be performed appear in that particular page.
Navigation
