EDIUS — User Reference Guide 219
Capturing from DirectShow Devices (Web Cameras, etc.)
To capture sources from a DirectShow device, do the following:
1. Select Settings>Hardware Settings from the Preview window menu
bar.
2. From the Hardware Settings dialog, click the “+” if necessary to expand
the “DirectShow Device Settings” tree.
3. Select “Device Settings” from the DirectShow Device Settings tree.
The dialog shown in Figure 199 appears.
Figure 199. DirectShow Device Settings Dialog
All DirectShow video devices connected to the EDIUS computer are dis-
played.
4. From the drop-down list associated with the desired video device,
select the desired audio capture device to be associated with that video
device.
5. Click the OK button.
Note Once the audio device had been selected for a particular video device, that
association remains in place unless it is changed. It is not necessary to set
the audio device before each capture operation unless a change is desired.
6. Select Capture>Input Settings from the Preview window.
