SDM-2020 Satellite Demodulator Revision 4
Front Panel Operation MN/SDM2020D.IOM
6–23
6.1.5.5 Function Select: Configuration: Recall
CONFIGURATION XX
RECALL
The Configuration Recall (XX = 1 through 10) menu allows the user to recall a
previously saved configuration setup. Upon entry, select memory location 1 through 10
by pressing [
↑] or [↓].
Press to execute the recall.
6.1.6 Function Select: Monitor
FUNCTION SELECT
MONITOR
Press to review or edit the following sub-menus.
Function Select: Monitor: Raw BER
RAW BER
2.4 E-3
Displays the current BER or No Data (if carrier is not locked).
Range: m.m E-e.
Notes:
1. Low limit based on performance.
2. High limit based on data/code rate
Press [
←] or [→] to move the flashing cursor, and [↑] or [↓] to increment or decrement
the selected kbps. Press to execute the change.
