SDM-2020 Satellite Demodulator

Revision 4

Installation

MN/SDM2020D.IOM

3–3

3.1.1

Connector Pinout Definitions

Pinout “TYPE” is defined to described signal direction for each pin. The signal direction
is relative to the connector.

Definitions for Pinout Types

I (Input)

A signal goes into the connector.

O (Output)

A signal exits the connector.

I/O (Input/Output)

A signal both enters and exits the connector on the specified pin.

GND (Ground)

The pin is defined as being connected to a power supply ground or return.

N/A (Not Assigned)

The pin is not assigned within the system but may be routed to other connectors.
Usually defines spare pins.

N/C (No Connect)

The pin is not connected and is not used within the system.

N/U (Not Used)

The pin is not used but is routed and has other uses within the system.

FC (Form C)

The pin is connected to a “Form C” relay.
