SDM-2020 Satellite Demodulator Revision 4
Front Panel Operation MN/SDM2020D.IOM
6–22
Function Select: Configuration: Interface: Buffer Center
(Conditional)
Buffer Center
Yes/No
This configuration function is used to center the buffer. Choosing YES centers the buffer.
IMPORTANT
Available with G.703 interface. This requires that the optional Overhead
card is installed.
On entry, the current position of the buffer is displayed. Press [
↑] or [↓] to change the
format. Press to execute the change.
6.1.5.4 Function Select: Configuration: Save
CONFIGURATION XX
SAVE
The Configuration Save (XX = 1 through 10) menu allows the user to program
configuration parameters into non-volatile memory on the M&C. There are 10 memory
locations that may be used to store specific frequently used configuration setups.
After changing the configuration parameters to the desired settings, enter the
Configuration Save menu and select memory location 1 through 10 by pressing
[
↑] or [↓].
Press to execute the save.
