3–1
Chapter 3. EXTERNAL
CONNECTIONS
This chapter a description of external connections.
3.1 External Connections
The connectors for the main unit are shown in figure 3-1 or Figure 3-2 and Rear Panel RF
Input Connectors (Table 3-1).
Table 3-1. Rear Panel Connectors
Name Ref. Desig. Type Function
Remote J1 9-pin D, Female Remote control (M&C)
Fault J2 9-pin D, Female Relay Faults
Monitor J21 9 pin D, Female Performance Monitor
IF Input (Single-Channel)
(see Note 1) J23 Type F, Female RX IF input, LNB power out.
IF Input (4 Input)
(see Note 2) J23, J24,
J25, J26
Type F, Female RX IF Input LNB power out
Prime Power None Standard AC Power Input
GND None #10-32 Stud Chassis Ground
Data Interface Connectors See Applicable Chapter
Notes:
1. Single RX IF input is for earlier L-Band units and all 70/140 MHz demodulators. LNB
power is available only for L-Band.
2. The 4-channel input IF is only available for L-Band.
