SDM-2020 Satellite Demodulator Revision 4
Front Panel Operation MN/SDM2020D.IOM
6–59
Utility Interface
RS422 Interface Type
Interface Select DVB DM State Normal
INTF Mode Select Serial RR State Normal
LVDS Interface Type
INTF Mode Select Serial
ASI/RS422 Interface Type
Interface Select ASI DM State Normal
RX INTF Firmware FW/NNNNRR MC State Normal
RX INTF Firmware MM/DD/YYYY RR State Normal
ASI/LVDS Interface Type
Interface Select ASI RX INTF Firmware MM/DD/YYYY
RX INTF Firmware FW/NNNNRR LVDS Status RX LVDS
ECL/HSSI RX Interface Type
DTE Status Unavailable
G.703 Interface Type
1544 Framing Structure G.704 34368 Framing Structure G.751
2048 Framing Structure G.704 44736 Framing Structure G.752
6312 Framing Structure G.743 51840 Framing Structure STS-1
8448 Framing Structure G.742 RX INTF Firmware FW/NNNNRR
32064 Framing Structure G.752 RX INTF Firmware MM/DD/YYYY
SMPTE 310M Interface Type
RX INTF Firmware FW/NNNNRR RX INTF Firmware MM/DD/YYYY
TX INTF Firmware FW/NNNNRR TX INTF Firmware MM/DD/YYYY
Utility System
Time 12:00AM M&C Firmware MM/DD/YYYY
Date 7/04/76 Boot Firmware FW/NNNNRR
Remote Baud Rate 9600 bit/s FPGA Firmware FW/NNNNRR
Remote Address 1 FPGA Firmware MM/DD/YYYY
Remote Type RS485 (4-Wire) LNB Current Limit
(see Note 3)
LO = 0 mA
HI = 0 mA
Year Display 4-Digit LNB Voltage
(see Note 4)
13 VDC
Display Contrast 64 AUX RF IN CTRL
(see Note 5)
Off
M&C Firmware FW/NNNNRR
Utility Demod Options
Modem Emulation
(see Note 5)
Disabled
Notes:
1. Not applicable with G.703 interface installed.
2. Applicable with G.703 interface installed.
3. For L-Band only.
4. 70/140 MHz only
5. For FW/7734 only.
