SDM-2020 Satellite Demodulator Revision 4
Front Panel Operation MN/SDM2020D.IOM
6–21
Function Select: Configuration: Interface: RX Coding Format
(Conditional)
RX CODING FORMAT
AMI
IMPORTANT
Available with G.703 interface. This requires that the optional Overhead
card is installed.
Programs the transmitter for AMI, B8ZS, HDB3, and B3ZS coding.
On entry, the current format for the RX CODING is displayed. Press [
↑] or [↓] to change
the format. Press to execute the change.
Function Select: Configuration: Interface: Buffer SIze
(Conditional)
BUFFER SIZE
AMI
Sets the size of the buffer.
On entry, the current buffer length is displayed. Press [
↑] or [↓] to select the desired
buffer size.
IMPORTANT
1. Available with G.703 interface. This requires that the optional
Overhead card is installed.
2. If selecting milliseconds, choose from 2 to 32 milliseconds, in
increments of 2 milliseconds or 0 (Bypass).
