SDM-2020 Satellite Demodulator

Revision 4

Front Panel Operation

MN/SDM2020D.IOM

6–36

(FAULT LABEL)

-----------

Displays the stored date and time of a fault or alarm, such as:

• Battery/Clock
• -12 Volt Supply
• +12 Volt Supply
• +5 Volt Supply
• Controller
• LNB

Function Select: Stored FLTS/ALMS: UNAVAL SECONDS

UNAVAL SECONDS 0

STORED TIME/DATE

A fault is indicated if the Reed-Solomon Codec could not correct bit errors in one block
of serialized data in any given second.

Function Select: Stored FLTS/ALMS: CLEAR??

CLEAR??

STORED FAULTS

To clear the currently logged stored faults, press when the “Clear Stored
Faults/YES?” selection is displayed.

6.1.9

Function Select: Utility
