SDM-2020 Satellite Demodulator Revision 4
Remote Control Commands MN/SDM2020D.IOM
A–23
A.1.15 Bulk Consolidated Status
Bulk
Consol.
Status Command:
Response:
Status:
Response: >add/BCS_p1,p2,p3, . . . pn'cr''lf']
This command causes bulk demodulator status to be returned.
To reduce the length of the response, message parameter data
are returned without identifiers. However, parameter
identification can be determined by order of return. Each status
parameter is terminated with a ',' (comma) except for the last
parameter which has the standard message termination
sequence ('cr''lf']). Most of the data returned is formatted the
same way as the single command status request (refer to the
appropriate portions of this document in preceding sections).
Additional configuration status of new options and features will
always be appended to the end.
Where 'pn' is the last parameter returned.
Parameter
Number
Parameter Name
(Command Reference)
Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
MODEM REMOTE/LOCAL mode.
Demodulator IF
(ref. 'DF_' command).
Demodulator rate
(ref. 'DR_' command).
Demodulator rate
(ref. 'ASR_' command).
Descrambler enable
(ref. 'DE_' command).
Reserved.
Sweep Width Range
(ref. 'SWR_' command).
Sweep Reacquisition
(ref. 'SR_' command).
Reserved.
Receive clock phase
(ref. 'RCP_' command).
Receive data phase
(ref. 'RDP_' command).
Receive data fault
(ref. 'RDF_' command).
Reserved.
Reserved.
DVB Framing Type
(ref. 'RDVB_' command).
Demodulator Spectrum Rotation
(ref. 'DSR_' command). p1 = n, where 'n' is '0' (LOCAL), '1' (REMOTE).
p2 = nnnn.nnnn, IF frequency in MHz.
p3 = nnnn_mmm.mmmmmm, code rate/data rate in Mbps.
p4 = nnnn_mm.mmmmmm, code rate/symbol rate in Msps.
p5 = n, where 'n' is '0' (off) or '1' (on).
p7 = nnnnn, sweep range in Hertz.
p8 = nnn, reacquisition time in seconds.
p10 = n, where 'n' is '0' (NRM), '1' (INV).
p11 = n, where 'n' is '0' (NRM), '1' (INV).
p12 = n, where 'n' is '0' (None), '1' (Data stable), '2' (AIS).
p15 = n, where n = '1' (188), '2' (187 (NONE), or '3' (204).
p16 = n, where 'n' is '0' (NRM), '1' (INV).
