Comtech EF Data SDM-2020 User Manual
Page 118
SDM-2020 Satellite Demodulator
Revision 4
Front Panel Operation
MN/SDM2020D.IOM
6–54
Displays the LNB voltage as 13, 18, or 24 VDC.
Notes:
1. With 4-Channel L-Band Card installed only.
2. 1-Channel L-Band Card is 24 VDC only, no user selection.
Function Select: Utility: System: AUX RF IN CTRL (Conditional)
AUX RF IN CTRL
OFF
IMPORTANT
For FW/7734-1 only.
Programs the AUX RF IN CTRL On or Off.
Upon entry, the current status is displayed. Press [
↑] or [↓] to change the selection. Press
