4–1

Chapter 4. ETHERNET-BASED

REMOTE PRODUCT

MANAGEMENT

4.1

Introduction

Ethernet-based remote management and control of the SPOD is available when the appropriate

adapter cable, connected to the SPOD ‘J6 | COM1’ 19-pin communications port.

This interface is generally modeled after Comtech EF Data’s LPOD Outdoor Amplifier/ Block Up

Converter (BUC) product interface. LPOD-specific operation (e.g., BUC and LNB) is disabled for the

SPOD Ethernet interface.

1) TO PROCEED WITH ETHERNET-BASED REMOTE PRODUCT MANAGEMENT,

ASSUMPTIONS ARE MADE THAT:

The SPOD is operating with the latest version firmware files.

The SPOD is connected to a user-supplied Windows-based PC as follows:

o

The PC’s Ethernet port is connected to the SPOD ‘J6 | COM1’ port using

the available CA-0000352 Ethernet Interface Cable (part of CEFD Kit KT-

0000203) in combination with a user-supplied hub or switch.

o

The PC is running a terminal emulation program (for operation of the

SPOD Telnet Interface) and a compatible web browser (for operation of

the SPOD Web Server Interface).

The SPOD’s Management IP Address has been noted.

2) USE OF THE ETHERNET-BASED SNMP INTERFACE IS RECOMMENDED ONLY FOR

ADVANCED USERS. ALL OTHER USERS ARE STRONGLY ENCOURAGED TO USE THE

SPOD WEB SERVER INTERFACE FOR REMOTE MONITOR AND CONTROL (M&C) OF

THE SPOD.
