SPOD C-, X-, or Ku-Band Outdoor Amplifier MN-SPODPSX
System Connections, Installation and Startup Revision 1
2–10
2.4 SPOD Standalone Installation
Several kits are available from Comtech EF Data to mount and install Standalone or 1:1
Redundancy SPODs, depending on the type of unit ordered and its operational frequency.
Figures on the pages that follow illustrate available Standalone mounting kits:
FIGURE CEFD PART NO. DESCRIPTION
2-7 PL/12319-1 Universal Pole Mounting Kit
2-8 KT-0000095 PS 1/PS 1.5 Single Unit Mounting Kit
2-9 KT-0000125 PS 2 Single Unit Mounting Kit
2-10 KT-0020524 PS 2 Single Unit Shelf Style Mounting Kit
See Appendix A. 1:1 REDUNDANCY for the available assembly kit options for 1:1 SPOD
redundancy configurations.
See Appendix B. CABLE DRAWINGS for information pertaining to the cables that are available
for use with the SPOD in Standalone or 1:1 Redundancy operation.
2.5 Power-up the SPOD
WARNING!
NEVER TURN THE UNIT ON WITHOUT PROPER WAVEGUIDE
TERMINATION ON THE ‘J2 | RF OUT’ PORT. INDIVIDUALS CAN BE EXPOSED TO
DANGEROUSLY HIGH ELECTROMAGNETIC LEVELS.
The SPOD does not have a ‘Power On/Off’ switch. It is powered ON by connecting the ‘J3 |
POWER IN’ connector to the appropriate prime power source. The Mute or Transmit status of
the SPOD automatically comes up in the last stored state (factory default = Transmit on, not
muted).
