1.4 Summary of Specifications
1.4.1 Characteristics
Band Model RF Output Frequency (see Note) P
sat
(Typical) P1dB (Guaranteed)
C-Band
PS1-32C
Standard:
5.850 – 6.425 GHz
Optional:
5.850 – 6.650 GHz
5.850 – 6.725 GHz
InSat C:
6.725 - 7.025 GHz
45 dBm (32 W) 44 dBm (25 W)
PS1-50C 47 dBm (50 W) 46 dBm (40 W)
PS1-60C 48 dBm (60 W) 47 dBm (50 W)
PS1.5-80C 49 dBm (80 W) 48.5 dBm (70 W)
PS1.5-110C 50.4 dBm (110 W) 49.5 dBm (90 W)
PS1.5-125C 51 dBm (125 W) 50 dBm (100 W)
PS2-125C 51 dBm (125 W) 50 dBm (100 W)
PS2-150C 51.8 dBm (150 W) 51 dBm (125 W)
PS2-200C 53 dBm (200 W) 52.5 dBm (175 W)
PS2-250C 54 dBm (250 W) 53dBm (200 W)
X-Band
PS1-32X
7.900 – 8.400 GHz
45 dBm (32 W) 44 dBm (25 W)
PS1-50X 47 dBm (50 W) 46 dBm (40 W)
PS1-60X 48 dBm (60 W) 47 dBm (50 W)
PS1.5-80X 49 dBm (80 W) 48.5 dBm (70 W)
PS1.5-110X 50.4 dBm (110 W) 49.5 dBm (90 W)
PS1.5X 51 dBm (125 W) 50 dBm (100 W)
PS2-125X 51 dBm (125 W) 50 dBm (100 W)
PS2-150X 51.8 dBm (150 W) 51 dBm (125 W)
PS2-200X 53 dBm (200 W) 52.5 dBm (175 W)
PS2-250X 54 dBm (250 W) 53dBm (200 W)
Ku-Band
PS1-20Ku
Standard:
14.00 – 14.50 GHz
Optional:
13.75 – 14.50 GHz
43 dBm (20 W) 42 dBm (16 W)
PS1-32Ku 45 dBm (32 W) 44 dBm (25 W)
PS1-40Ku 46 dBm (40 W) 45 dBm (32 W)
PS1.5-50Ku 47 dBm (50 W) 46 dBm (40 W)
PS1.5-60Ku 48 dBm (60 W) 47 dBm (50 W)
PS2-100Ku 50 dBm (100 W) 49 dBm (80 W)
PS2-125Ku 51 dBm (125 W) 50 dBm (100 W)
Note: Allow 1 dB degradation from 13.75 to 14.0 GHz and 6425 to 6725 MHz.
