7. Measure from the bottom of the
print area to the pivot point on the
field. Write the distance, in your
selected units, in box B5.
Ranges for row location
English 0-800
Metric 0-2032
Dots 0-1536
8. Measure from the left edge
of the print area to the pivot
point. Write the distance,
in your selected units, in
box B6.
Ranges for column location
English 0-400
Metric 0-1118
Dots 0-768
9. Write the number of the bar code
you want to use in box B7.
Number Bar Code
1 UPC-A
2 UPC-E
3 Interleaved 2 of 5
4 Code 39
5 Codabar
6 EAN-8
7 EAN-13
8 Code 128
NOTE: Codabar and Interleaved 2 of 5 bar codes validate
the data in the field. If the data is invalid, the
printer prints a blank field. The other fields do not
validate the data.
See "The Print Area,"
earlier in this chapter,
for information about
no print zones.
9406 System Administrator’s Guide
2-30
