Bar Code Field Definition
Message Structure
Syntax B1,B2,B3,B4,B5,B6,B7,B8,B9,B10,B11,B12
p
B1. B Indicates the definition is a bar code field. Enter B.
B2. field # Unique number from 1-30 to identify this field.
B3. # of char Maximum number of characters. The range depends
on the type of bar code. See "Defining Bar Code Fields," in
Chapter 2, "Designing a Format."
B4. Fix/Var Fixed or variable length field. Values:
F Fixed length
V Variable length field.
B5. row Distance from bottom of print area to lower left corner of field
(The bottom exits the printer first.) Ranges:
English 0-800
Metric 0-2032
Dots 0-1536.
B6. column Distance to lower left corner of field from left edge of print
area. Ranges:
English 0-400
Metric 0-1118
Dots 0-768.
B7. font Bar code.
1 UPC-A
2 UPC-E
3 Interleaved 2 of 5
4 Code 39 (no check digit)
5 Codabar
6 EAN-8
7 EAN-13
8 Code 128
