B8. density Bar code density. See chart below. Defaults are listed in
bold.
Density values are theoretical and print quality variations can
affect the actual values. Calculations are based on a 5.2 mil
dot element size.
*Actual characters printed, excluding start, stop, or checksum
characters.
Bar Code Density
Code
Narrow-to-
Wide
Ratio
Density (CPI) Nominal
Width
(dots/mils)
UPC/EAN
2
4 1:1.0
1:1.0 80%
120% 2/10.4
3/15.7
Code 128*
4
6
8 1:1.0
1:1.0
1:1.0 4.37/8.74
5.83/11.66
8.74/17.48 2/10.4
3/15.6
4/20.8
Codabar
(NW7)
2
3
4
5
7
8 1:30
1:2.5
1:2.5
1:2.0
1:3.0
1:2.5 2.00
2.91
4.37
4.81
8.01
8.74 8/41.9
6/31.4
4/20.9
4/20.0
2/10.4
2/10.4
Code 39
3
4
6
7 1:2.5
1:3.0
1:3.0
1:2.5 3.32
4.01
6.01
6.63 4/20.9
3/15.6
2/10.4
2/10.4
I2 of 5
1
2
3
4
5
6
7
8
9
10
11
12
13 1:3.0
1:2.5
1:3.0
1:2.5
1:3.0
1:2.5
1:2.0
1:2.33
1:2.0
1:3.0
1:3.0
1:2.5
1:2.0 1.02
2.00
3.05
4.01
5.34
6.01
6.87
8.36
9.16
10.68
10.68
12.02
13.74 21/109.9
12/62.8
7/36.6
6/31.4
4/20.9
4/20.9
4/20.9
3/15.7
3/15.7
3/15.6
3/15.6
2/10.4
2/10.4
On
li
ne
I
n
fo
rm
a
tio
n
