by-channel basis. If the PLL has not locked to a stable clock source, the DPA circuit might lock pre-
maturely to a non-ideal phase tap. Use the
rx_reset
port to keep the DPA in reset until the PLL lock
signal is asserted and stable.
In Stratix GX, Stratix II, Stratix II GX, HardCopy II, and Arria GX devices, when using the
rx_reset
port,
the ALTLVDS_RX parameter editor allows you to choose whether or not to automatically reset the bit
serial FIFO when the
rx_dpa_locked
signal asserts for the first time. This is a useful feature because it
keeps the synchronizer FIFO in reset until the DPA locks. To provide optimal timing between the DPA
domain, it is important to keep the FIFO in reset until the DPA locks.
With Stratix III, HardCopy III, Arria II GX, Arria II GZ devices and later generations of these devices, the
rx_dpa_lock
signal asserts only after a specific number of transitions are detected in the parallel data
stream. You must not assert
rx_fifo_reset
port until the
rx_dpa_lock
signal asserts, otherwise, there
will be no data transitions in the parallel data, and the
rx_dpa_lock
signal will never assert.
Note: Altera recommends asserting the
rx_fifo_reset
port after the
rx_dpa_locked
signal asserts, and
then deassert the
rx_fifo_reset
port to begin receiving data.
Each time the DPA shifts the phase taps during normal operation to track variations between the relation‐
ship of the reference clock source and the data, the timing margin for the data transfer between clock
domains is reduced.
For Stratix GX, Stratix II, Stratix II GX, HardCopy II, and Arria GX devices, when the ALTLVDS_RX IP
core deasserts the
rx_dpa_locked
port to indicate that the DPA has selected a new phase tap to capture
the data. You can choose the options in the ALTLVDS_RX parameter editor if you want the DPA lock
signal to deassert after one phase step, or after two phase steps in the same direction (check device family
availability for this option).
With Stratix III, HardCopy III, Arria II GX, Arria II GZ devices and later generations of these devices, the
ALTLVDS_RX asserts the
rx_dpa_locked
port upon initial DPA lock. This port remains asserted
throughout the operation until the ALTLVDS_RX IP core asserts the
rx_reset
or
rx_dpa_lock_reset
ports. The
rx_dpa_locked
port does not indicate if the DPA has selected a new phase.
Note: Altera recommends using the data checkers to ensure data accuracy.
Resetting the DPA
When the data becomes corrupted, you must reset the DPA circuitry using the
rx_reset
port and
rx_fifo_reset
port.
Assert the
rx_reset
port to reset the entire DPA block. This requires the DPA to be trained before it is
ready for data capture.
Note: Altera recommends using the option to automatically reset the bit serial FIFO when the
rx_dpa_locked
signal rises for the first time, if available for your device family; otherwise, toggle
the
rx_fifo_reset
port after
rx_dpa_locked
is asserted. This option ensures the synchronization
FIFO is set with the optimal timing to transfer data between the DPA and high-speed LVDS clock
domains.
Assert the
rx_fifo_reset
port to reset only the synchronization FIFO. This allows you to continue
system operation without having to re-train the DPA. Using this port can fix data corruption because it
resets the FIFO; however, it does not reset the DPA circuit. In Stratix GX, Stratix II, Stratix II GX,
HardCopy II, and Arria GX devices, the
rx_dpa_locked
port remains in its previous state; if it was
deasserted, it remains deasserted and you are not be able to use it to know when the DPA is using the ideal
phase tap for data capture.
When the DPA is locked, the ALTLVDS block is ready to capture data. The DPA finds the optimal sample
location to capture each bit. The next step is to set up the word boundary using custom logic to control
the
rx_channel_data_align
port on a channel-by-channel basis.
