26
Logging Data
Figure 15. Error Rate History Tab
The Err Rate History tab includes two timestamps: the timestamp for the oldest
and the newest update points on the trend graph. You can set the rate at which
this display is updated, as well as the number of points that are displayed on the
chart, with the statistics options tabs. See
for more
information.
Setting Statistics Options
You can configure the statistics options to control how the protocol analyzer
collects data from the network and how that data is displayed. To set the
statistics options, perform the following steps:
1. Select Statistics → Statistics Options to open the Statistics Options
dialog, as shown in Figure 16 on page 27. The General tab displays.
