Street Light Bridge Integrator’s Guide
67
e. Click OK to return to the device Web page.
4. If the external device interface has changed, you need to load a new XIF
file for the device onto the Segment Controller:
a. In the Template property, click the … button to the right.
b. The Choose File dialog opens.
c. Expand either the LonMark (XIF) or Template folder
depending on whether you are using a .xif or .xml file for the
external device interface. If the device being upgraded is located
in the LNS tree, the Template folder is not available.
d. For an XIF file, expand the subfolders containing the XIF file to
be loaded onto the Segment Controller, and then click the XIF
file.
e. Click OK to return to the device Web page.
5. Click Submit.
6. Download the application image to the selected devices: Right-click one
of the selected devices in the Segment Controller tree, select Manage,
and click Download Image in the shortcut menu. Alternatively, you
can clear and then select the Smart Network Management checkbox to
the left of the Application Image property in the device Web page and
click Submit.
7. Activate the XIF files for the devices (if necessary): Right-click one of the
selected devices in the Segment Controller Segment Controller tree,
select Manage, and click Activate Template in the shortcut menu.
Alternatively, you can clear and then select the Smart Network
Management checkbox to the left of the Template property in the device
Web page and click Submit.
