100 Controlling a Street Lighting Network
The Example Schedule
The calendar view shown below displays the schedule defined in the previous
sections. The color coding for parts of the calendar view defines the following
scheduled events:
• Light grey with no border represents daily LAMP_ON_60 presets
• Light grey with a blue border represents weekend LAMP_ON_60 presets
• Dark grey with a grey border represents daily LAMP_ON_100 presets
• White with a grey border represents daily LAMP_OFF presets
• White with a blue border represents weekend LAMP_OFF presets
