Page 30
20
Installation for the Street Lighting Solution
Figure 7. Extending the Street Light Bridge Installation
Adding Multiple RF Hops
Because CRD 3000 Street Light Bridge modules provide communications across
power line boundaries, you can connect them in a series to provide maximum
range extension. Figure 8 on page 21 shows such an extension from the
configuration shown in Figure 7. By adding CRD 3000 Street Light Bridge
modules in series as shown in the bottom portion of Figure 8, you can create
complex networks to provide power line and RF communications for almost any
physical configuration of luminaires in a street lighting solution.
