Street Light Bridge Integrator’s Guide

assume that the Segment Controller cannot communicate with the luminaire,

and you should proceed to step 3.
If you install the luminaires before the Segment Controller, the Segment

Controller will discover and commission all of the luminaires; however, this

process could take some time.
After an installed luminaire is discovered and commissioned by the Segment

Controller, the lamp should turn off. For any that do not turn off, proceed to Step

3 to install CRD 3000 Street Light Bridge modules; the Segment Controller will

discover the installed luminaires through the CRD 3000 Street Light Bridge

modules.

Step 3: Install CRD 3000 Street Light Bridge Modules

Install a CRD 3000 Street Light Bridge module to extend the communications

range of the Segment Controller.
Return to any previously installed luminaire for which the lamp is off (that is, it

has communications with the Segment Controller). Install the CRD 3000 Street

Light Bridge module on the luminaire or on a pole near the luminaire, and record

its physical location (GPS coordinates, pole ID, or map grid reference) and its

Neuron ID (the barcoded number printed on or attached to the module); or

alternatively, let the Segment Controller automatically discover and commission

the CRD 3000 Street Light Bridge module.
You can install the CRD 3000 Street Light Bridge module in the luminaire’s

photocell receptor after removing the photocell. For luminaraires that do not

have a photocell receptor, you need to add a locking-type photocontrol receptacle

that conforms to the ANSI C136.10 standard.

Insert the module into the

photocell receptor or locking-type photocontrol receptacle, and turn the module ¼

turn clockwise to lock it into position.
The CRD 3000 Street Light Bridge module has a green LED to indicate that it is

receiving power. In addition, if this LED is on solid, the CRD 3000 Street Light

Bridge module has been discovered and commissioned by the Segment Controller;

if this LED is flashing slowly, the CRD 3000 Street Light Bridge module has not

yet been commissioned.
Install a second CRD 3000 Street Light Bridge module on a luminaire (or on a

nearby pole) for which the lamp is on (that is, the luminaire does not have

communications with the Segment Controller). This second CRD 3000 Street

Light Bridge module should have direct line-of-sight with the previously installed

CRD 3000 Street Light Bridge module. Ensure that the two modules are within

85 meters (275 feet) of one another.
Verify that the newly installed CRD 3000 Street Light Bridge module’s amber

LED is on to indicate that the module has good radio frequency (RF)

communication with a previously installed module; see Verifying Successful

Installation on page 17. If the newly installed CRD 3000 Street Light Bridge

module does not have a sufficient RF signal with a nearby CRD 3000 Street Light

Bridge module, reinstall the CRD 3000 Street Light Bridge module in a different

Locking-type photocontrol receptacles are available from companies such as Ripley Lighting

Controls (for example, their 5927 or 5926 Receptacle With Cast Housing can accommodate the

Street Light Bridge module).
