Street Light Bridge Integrator’s Guide 59
Black (Installed)
• Commissioned. The device has successfully been
installed.
Orange (Installation in Progress)
• Pending Commission. The Segment Controller has
identified that it needs to commission the device.
• Pending Download. The Segment Controller has been
instructed to download an application image to the
device.
• Never Reached. During the initial installation
attempt, the device has not received messages from the
Segment Controller.
Red (Error)
• Commission Error. The device has not been
commissioned. Most likely this state is a result of a
communication failure, but it could also be caused by a
device failure.
• Download Error. An application image has not been
downloaded to the device. Most likely this state is a
result of a communication failure, but it could also be
caused by issues such as the device having the wrong
model number, or the device and the application image
file (.apb extension) on the Segment Controller (to be
downloaded to the device) having mismatching program
IDs.
• Message Error. The Segment Controller cannot
communicate with the device after the calculated
number of retries (this state is classified as a hard
message error). The Segment Controller regularly
attempts to communicate with the device over an
approximate 5 minute period. If the device does not
respond during this time, its Online Status is changed
from “Down” to “Confirmed Down”.
