Features Your Field PC
Current Limits CF card slot: 3.3 V; SD card slot: 3.3 V;
USB Host: 5 V; 9-pin D-sub connector:
5 V on DTR line; recommended
maximum combined output current:
500 mA; short circuit protected
Power Voltage +12 VDC; Range +10 10-20
VDC; Current: Max 12 V @ 850 mA;
reverse polarity protection; over
voltage protection; auto shut off
Wireless
Communication
Options
Integrated Bluetooth or Bluetooth-
supported with CF or SD Bluetooth
card; Wi-Fi supported; wireless cellular
modem
Internal Clock Battery-backed real time clock
Enunciators External power/charge LED and
notifi cation LED; other enunciators on
system tray
Certifi cations FCC Class B, European CE Mark
EMI Meets FCC class B requirements
9-pin serial port pinouts
Pin # Description
1 Data Carrier Detect (DCD) Input
2 Receive Data (RCD) Input
