FingerTec Ingress User Manual
Page 18
18
1. Go to
Device
tab to select
Add Device
.
2. Select
Device
Type
and
Communication
Mode
then insert the information accord-
ingly.
Device Name:
Name the device for easy future reference.
Communication Key:
5-digit numeric secret password to secure the connection between device and
Ingress. Ingress must pair this key with device (under Dev ID) before connection establishes.
Auto Synchronize Device Time:
Activate this to allow Ingress to always synchronize the device with
the server date and time.
Settings for TCP/IP connection:
IP Address/URL: Insert the IP address of the device so Ingress can find it on the network to establish con-
nection.
For devices installed at remote site, you can insert the URL of the remote server into this column. In-
gress can link up with the device via Internet.
Port: Default TCP port (4370) of Ingress server to link up with device via network.
Settings for RS485 connection
Serial port: Define the serial port of the server in use to connect to the RS232/485 data converter.
Baud rate: Select the baud rate of RS485 network.
Settings for USB flash disk
Serial number: Serial number of device.
Device ID: Make sure you insert the same ID as the one set in the device. Ranges from 1 to 999.
Settings for Keylock
UDisk Path: Define the USB flash disk drive to read the basic info of Keylock
3. Check the box
Online
next to
Device Activation
to add the device into Ingress.
If an Internet connection is unavailable, you can activate the device by selecting
Offline
.
Ingress accepts a 12-digits alphanumeric code for offline activation, but this code may onle
be retrieved from your local resellers or
.
4. Click
Enable Device
to establish connection to the device.
Note:
You must plug in a USB flash disk to Keylock 7700/8800 to download a file name “X_udata”, where X is the Device
ID of the device used (e.g.: 1_udata). The file contains the serial number of the device and other important information.
Ingress can only add the Keylock 7700/8800 device into the list after it captures this file from the USB flash disk.
