Benchmark 1.5ln dual-fuel low nox boiler, Gf-121 – AERCO BMK 1.5 LN Dual Fuel Feb 2013 User Manual
Page 40
CHAPTER 3: CONTROL PANEL OPERATION
Page
40 of 162 PR2: 05/09/12
Benchmark 1.5LN Dual-Fuel Low NOx Boiler
Operation and Maintenance Manual
OMM-0041_0C
GF-121
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526-0288
100
DETAIL “A”
TO BLOWER
AIR IN
DIAL
(DETAIL “A”)
STEPPER
MOTOR
Figure 3-4: Air/Fuel Valve In Purge Position
AIR/FUEL
VALVE OUTLET
TO BLOWER
BLOWER
PROOF
SWITCH
Figure 3-5: Blower Proof Switch
