CHAPTER 3: CONTROL PANEL OPERATION

Page

38 of 162 PR2: 05/09/12

Benchmark 1.5LN Dual-Fuel Low NOx Boiler

Operation and Maintenance Manual

OMM-0041_0C

GF-121

AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526-0288

Table 3-6: Combustion Cal Menu

Available Choices or Limits

Menu Item Display

Minimum

Maximum

Default

CAL Voltage 16%

.25

8.20

1.80v

CAL Voltage 30%

.25

8.20

3.20v

CAL Voltage 45%

.25

8.20

3.70v

CAL Voltage 60%

.25

8.20

3.80

CAL Voltage 80%

.25

8.20

4.60

CAL Voltage 100%

.25

8.20

6.00

SET Valve Position

0%

100%

0%

Blower Output

Monitor Blower Output Voltage

.00

2.9 START SEQUENCE

When the Control Box

ON/OFF switch is set to the ON position, it checks all pre-purge

safety switches to ensure they are closed. These switches include:

Safety Shut-Off Valve Proof of Closure (POC) switch

Low Water Level switch

High Water Temperature switch

High Gas Pressure switch

Low Gas Pressure switch

Blower Proof switch

Blocked Inlet switch

If all of the above switches are closed, the

READY light above the ON/OFF switch will light

and the unit will be in the Standby mode.
When there is a demand for heat, the following events will occur:

NOTE

If any of the Pre-Purge safety device switches are

open, the appropriate fault message will be

displayed. Also, the appropriate fault messages will

be displayed throughout the start sequence, if the

required conditions are not observed.

1. The

DEMAND LED status indicator will light.

2. The unit checks to ensure that the Proof of Closure (POC) switches in both the gas and

propane Safety Shut-Off Valves (SSOV) are closed. See Figure 3-3 for SSOV

locations.

3. With all required safety device switches closed, a purge cycle will be initiated and

the following events will occur:
a) The Blower relay energizes and turns on blower.
b) The Air/Fuel Valve rotates to the full-open purge position and closes purge position

switch. The dial on the Air/Fuel Valve (Figure 3-4) will read 100 to indicate that it is

full-open (100%).

c) The

VALVE POSITION bargraph will show 100%.
